SGP Clear Laminated Tempered Glass

HENGXUN is Chinese professional SGP Clear Laminated Tempered Glass manufacturer and exporter.HENGXUN SGP Clear Laminated Tempered Glass use SGP interlayer which is crated by American brand Dupont and is five times stronger and up to 100 times stiffer than PVB film. Our products cover most of the European and American markets. You are most welcome to inquiry.

Send Inquiry

Product Description

Hengxun SGP Clear Laminated Tempered Glass is made of two or more pieces of high quality Clear tempered glass and SGP interlayer by advanced bond technology.The sandwiched interlayer gives the glass structural integrity and keeps it from shattering apart like tempered glass might.

HengxunSGP Clear Laminated Tempered GlassAdvantages:

1. Extremely high safety:Hengxun SGP Clear Laminated Tempered Glass will stay standing when both sides are broken as compared to“PVB laminated glass”it will fall down or break when both sides have become damaged. The SGP laminated glass is five times stronger and up to 100 times stiffer than PVB laminated glass.

2. Clarity: The SGP yellow index is smaller than 1.5, while normally the PVB yellow index is 6-12, so the SGP laminated glass is much more clear than PVB laminated glass.

3.Sound control: SGP interlayer is an effective absorber of sound.

Hengxun SGP Clear Laminated Tempered Glass Parameter (Specification)

Composition	Tempered glass+ SGP film+ tempered glass
Thickness	Glass Thickness: 5+5mm, 6+6mm, 8+8mm, 10+10mm, 12+12mm 15+15mm, with different thickness interlayer, Triple layer, four layer, five layer, etc. Interlayer Thickness: SGP:0.89mm, 1.52mm, 2.28mm etc.
Size	Custom size, Max: 3300x13000mm
Glass Color	clear, ultra clear, grey, green, blue, bronze
SGP color	Clear
Shape	Flat / Curved, customized
Glass Type	Annealed or toughened laminated glass in Clear, Tinted, Reflective, Low Iron, Etched, Mirrored, Textured, Colorsmart,Thermocolour, screen printing, and Low E combinations
Processing	Cut to size, custom shape, polish edges, drill holes, cutouts, cut notches, etching, printing, sandblasting, safety corners, etc.
Quality Standard	Meet ISO, CCC, SGCC ANSI Z97.1-2015, CE EN12150 EN12600 EN14449:2005, BS6206 etc. standard

HengxunSGP Clear Laminated Tempered GlassApplication

Hengxun SGP Clear Laminated Tempered Glass is widely used in areas where a safety glass is needed such as Bullet-proof glass,Explosion-proof glass,High-speed train windshield,Railings -SGP hurricane glass, Ceiling, skylight,staircase, steps, floor, fence,canopy, partition,etc.

Hengxun SGP Clear Laminated Tempered Glass Details

Hengxun SGP Clear Laminated Tempered Glass is produced by adhering two or more pieces of tempered glass together by a SGP interlayer film.

The interlayer film will continue to hold the glass together in the event that it is struck or dropped. As one of the safest glass in the world, SGP Clear Laminated Tempered Glass is widely used in areas where a safety glass is needed.
